Name: EC-AIRV-20L/BLDC
Brand: WaterPAL International Co., Ltd
SKU: NO171

1 / 7

EC-AIRV-20L/BLDC

Product brief：

Delivery pumps (also known as demand pumps,dispensing pumps and transfer pumps) are designed for intermittent duty, though most models can be run continuously for hours at a time. These diaphragm pumps are controlled by a pressure switch.
Available for 20 LPM/HDC. Voltage 220-240 V/AC.

Features

Variable frequency motor
Steady RPM
Integrated PCB driver
Over Voltage Protection
Over Current Protection
Locked Rotor Protection

Specifications

Voltage：220-240VAC
Port：1/2" NPT
Inlet Pressure：0 psi
Pressure Switch：0.42MPA Off
Open Flow：≧ 20 LPM
Maximum power： 265W
Self-Priming Height：≧ 2M
Weight：1.95kg
Dimensions：218x199x186mm

Performance Curve Chart
